Smart Pump Automation
Smart Pump Automation & IoT Control Panels in Pune & PCMC
- Save 30% - 40% on Electricity Bills via Variable Frequency Drives (VFD)
- Automated Tank Level Management (Underground to Overhead Transfer)
- Comprehensive Protection: Dry-Run, Overload, Phase Reversal & Single Phasing
- Live Cloud Dashboard, Mobile App Alerts & GSM/SMS Fault Notificat
Intelligent Pumping Architectures
From IoT GSM to Central SCADA
Narmada Water Tech delivers modern, connected pump automation solutions:
Automatic Tank-to-Tank Transfer Systems
Utilizing hydrostatic level transmitters or ultrasonic level sensors in Underground (UGT) and Overhead (OHT) tanks. The system automatically initiates pumping when the OHT drops below a programmable low setpoint and cuts off before overflow, verifying adequate water level in the UGT to prevent cavitation.
Hydro-Pneumatic Pressure Boosting (HNS) Systems
Constant water pressure throughout multi-story residential towers, commercial offices, and industrial plants. Multi-pump skids driven by Danfoss or ABB Variable Frequency Drives (VFD) adjust motor RPM instantaneously in response to real-time plumbing demand, maintaining constant pressure (e.g., 3.5 bar) while cutting energy consumption by up to 40%.
WTP / STP / ETP Sequential Process Automation
PLC-controlled automation (Siemens / Schneider / Delta) for automatic backwashing of sand and carbon filters, alternating duty-standby air blowers, and proportional chemical dosing tied to digital flowmeters and pH transmitters.
Smart IoT Telemetry & Cloud SCADA
Cloud-connected 4G/GSM IoT gateways logging runtime hours, power consumption (kWh), line pressure, water flow (m³/day), and fault alarms. Society facility managers and plant engineers receive real-time alerts via mobile apps and SMS.
Technical Comparison
Technical Features & Protection Matrix
Automation Module |
Hardware & Components |
Primary Function |
Benefits & Payback |
|---|---|---|---|
|
IoT Level Automation |
Hydrostatic level sensors, 4G GSM Controller
|
UGT to OHT automated level monitoring & pump trip |
Zero tank overflows, zero water wastage
|
|
VFD Pressure Boosting
|
ABB / Danfoss VFDs, SS304 Pressure Transmitters
|
Modulates pump RPM to maintain constant pressure
|
30-40% power reduction, soft-start eliminates water hammer
|
|
Comprehensive Motor Protection
|
L&T / Schneider MPCB, Phase Monitors, PTC Relays
|
Guards against dry-run, overvoltage, single phasing
|
Prevents motor rewinding costs and pump failure |
|
STP / ETP Process PLC |
Siemens S7-1200 PLC, 7" Color Touchscreen HMI
|
Automates blowers, dosing pumps, sludge cycle
|
Removes human error, ensures 100% MPCB log compliance
|
|
Cloud Analytics & App
|
MQTT IoT Gateway, AWS Cloud, Android/iOS App
|
Live tracking of flow, pressure, power & alarms
|
Predictive maintenance alerts, transparent society billing |
Pune & PCMC Deployments
Applications Across Residential & Industrial Pune
Wakad, Baner, Ravet, Moshi
Residential Housing Societies
Automated domestic, flushing, and fire-fighting pumping systems eliminating the need for 24-hour manual pump operators.
Kurkumbh, Paithan, Hinjawadi
Commercial IT Parks & Tech SEZs
Centralized SCADA monitoring of chilled water circulation, domestic booster pumps, and rainwater harvesting sumps.
Chakan, Bhosari, Ranjangaon
Industrial Manufacturing Facility
Raw water intake pump houses, cooling water recirculation loops, and hazardous effluent transfer stations.
Pune & PCMC
Municipal & PMRDA Lift Stations
Heavy-duty sewage and stormwater submersible pump automation with auto-alternating lead-lag logic.
Why Pune Societies & Builders Choose
Narmada Water Tech
IP55 Weatherproof Enclosures
Powder-coated CRCA steel panels protected against dust, humidity, and monsoon rains.
Tier-1 Switchgear
Exclusively using Schneider Electric, L&T, Siemens, and ABB contactors and circuit breakers for uncompromised safety.
Seamless Retrofitting
We upgrade existing manual star-delta or DOL starter panels into automated, VFD-driven smart panels within 6 hours.
Pune-Based Technical Support:
Fast local replacement of sensors, relays, and VFD modules across Pune and PCMC.
