Water Treatment Plant
Water Treatment Plant (WTP) Manufacturer in Pune & PCMC
- Complete Hardness Reduction from 800+ ppm to < 50 ppm for Boilers & Domestic Use
- Multi-Stage Media Filtration: Sand, Dual Media, Activated Carbon & Ultrafiltration
- Automatic PLC/Multiport Valve Backwashing with Minimal Water Wastage
- 100+ Commercial & Industrial WTPs Commissioned across Maharashtra
Advanced Water Treatment
Industrial & Commercial WTP Technologies
Pressure Sand Filters (PSF) & Dual Media Filters (DMF)
Removing suspended solids, turbidity, and colloidal matter down to 10-20 microns using multi-graded quartz sand, gravel, and anthracite coal.
Activated Carbon Filters (ACF)
Adsorbing dissolved chlorine, organic contaminants, pesticide residues, and unwanted odors using high-iodine virgin coconut shell activated carbon.
Automatic Water Softeners
Ion exchange resin units (Strong Acid Cation in sodium form) converting hard scaling salts (calcium and magnesium) into soluble sodium ions. Equipped with automated brine regeneration tanks and multiport valves.
Iron & Manganese Removal Filters
Utilizing catalytic media (Birm / Greensand Plus) to oxidize and filter out dissolved ferrous iron, preventing staining, pipe scaling, and plumbing corrosion.
Technical Parameters & Sizing Matrix
WTP Technical Sizing & Specification Matrix
Plant Capacity |
Flow Rate |
Primary Application |
Recommended Configuration |
Footprint (Sq. Ft.) |
|---|---|---|---|---|
|
Small Commercial / Hotel
|
1.0 - 3.0 m³/hr
|
Boutique hotels, restaurants, clinics |
PSF + ACF + Water Softener (FRP Vessels) |
60 - 100 sq.ft
|
|
Residential Society (100 Flats)
|
5.0 - 10.0 m³/hr
|
Borewell & tanker softening for domestic tap
|
Dual Media Filter + Dual Softener + UV/UF
|
150 - 250 sq.ft |
|
Large Society / IT Park
|
15.0 - 25.0 m³/hr |
Drinking water & plumbing grid conditioning
|
Clarifier + MGF + Softener Skid + Chlorine Dosing |
350 - 500 sq.ft |
|
Industrial Manufacturing |
30.0 - 50.0 m³/hr
|
Boiler feed, cooling tower makeup, paint shop |
Coagulation + PSF + ACF + Duplex Softener + UF
|
600 - 1000 sq.ft
|
|
Mega Industrial / Municipal
|
60.0 - 100+ m³/hr |
MIDC plant supply, central industrial utility
|
High-Rate Solids Contact Clarifier + Gravity Filter
|
Custom Civil Layout
|
Water Quality Transformation
Raw vs. Treated Water Parameters
Raw tanker and borewell water in areas like Wagholi, Kharadi, Hinjawadi, and Chakan often exhibits extreme hardness
and turbidity that ruins plumbing, scales heating elements, and causes skin irritation.
Total Hardness (as CaCO₃)
Reduced from 600 - 1200 mg/L down to < 50 mg/L or < 5 mg/L .
Turbidity
Reduced from 15 - 50 NTU down to < 1.0 NTU (Crystal clear).
Total Suspended Solids (TSS
Reduced from 80 - 150 mg/L down to < 2.0 mg/L.
Dissolved Iron
Reduced from 2.5 - 6.0 mg/L down to < 0.1 mg/L.
Pune & PCMC Deployments
Targeted Industrial Corridors
Chakan, Bhosari, Talegaon
Automotive & Ancillary Units
Conditioning rinse water, e-coat pre-treatment, and CNC coolant makeup.
Kurkumbh, Paithan, Hinjawadi
Pharmaceutical & Biotech
Raw water pre-treatment feeding purified water generators and multi-column distillation systems.
Pune
Food & Beverage Processing
High-purity ingredient water, bottle washing, and clean-in-place (CIP) water conditioning.
Pune
Residential Townships
Centralized water softening preventing scale formation in solar water heaters, geysers.
